EZLite-HxS

The EZLite-HxS series gives spectral data within a+/- 60° viewing cone, and is very fast. A full spectral map is made in less than 3mn. With 1s band pass filters regularly distributed in the middle range, the EZLite-HxS is the solution for angular spectral analysis.

Features & Benefits:

Non-contact measurement
Fast spectral measurements
Radiance, luminance and color data
High accuracy and reliability
Cooled CCD sensor

Applications:

Physico-realistic simulation
All kind of displays performances characterization in details
Grey levels analysis

Specification & Models:

Specification	Value
Viewing Angle	Azimuth angle: ±60° 0-360°
Measuring area	Diameters: 2mm, 1mm, 500μm, & 300μm
Density	Set of neutral density
Polarization	Optimal 3 polarizers: 0, 45 & 90° and 2 wave-plates
Optimum distance	(To ensure the light is coming from the same spot at any angle) 4,5mm
Spectral specs	Standard Optional: Spectral data extraction 15 bandpass filters on the visible range 400-700nm, 2 additional badpass filters between 700 and 900nm, Interpolation with steps between 1 and 5nm
Measurement time	Radiance with full resolution: <6mn Radiance with half resolution: <3mn Polarization with full resolution: <15mn
Accuracy	Wavelength resolution (nm): 20 Wavelength accuracy (nm): 1 Stray light (%): <0.1 Angular resollution (deg): 0.75 Radiance (W/Str/m2/nm): ±5% Chromaticity: 0.005 (for any stimulus) Ellipticity & polarization direction: ±2° up to 60° Polarization degree: ±2% up to 60°
Repeatability	Radiance: ±0.05% Luminance: ±0.05% Chromaticity: 0.001
Reflective options	Only Diffused
Use conditions	Temperature range: 0 to 30°C Humidity range: 0-85% non condensing
Interface	USB 2.0
Power	AC adapter (100-240V 50/60Hz)
Current consumption	90W
Weight	10Kg
