Thermopile Multi-Channel Detector by Configuration
Note 1: All detectors are available with Ne, N2, Ar or Xe encapsulation gas. Exceptions are ST60LCC, SLA32 and SLA64 which come with N2
Note 2: Other package hole sizes are available for single element detectors. Please contact us for details.
Specification & Models:
| Model # | Channels | Technology | Package Size | Active Area Size (mm) | Output Voltage (μV) | Signal to Noise Ratio | Resistance (kΩ) | Time Constant (ms) | Thermistor Option | Internal Aperture |
|---|---|---|---|---|---|---|---|---|---|---|
| 2M Quad | 4 | Thin Film | TO-82 x 2 | 250 | 19,531 | 108 | 5 | Internal | Standard | |
| DR262 | 1 | Thin Film | TO-5 | .65 x .45 | 6,845 | 5.5 | 38 | External | No | |
| DR342 | 1 | Thin Film | TO-5 | .16 x .41 | 1510 | 88 | 38 | External | Standard | |
| DR462 | 1 | Thin Film | TO-8 | .62 x .1 | 16,406 | 104 | 0 | External | Standard | |
| 10 Channel | 10 | Thin Film | TO-8 | .16 x .41 | 1510 | 88 | 38 | Internal | Standard | |
| ST120 Dual | 2 | Silicon | TO-5 | 1.2 x 1.2 | 1654 | 30 | 190 | 25 | Internal | No |
| ST120 Quad | 4 | Silicon | TO-5 | 1.2 x 1.2 | 1403 | 64 | 90 | 25 | Internal | No |
| ST150 Dual | 2 | Silicon | TO-5 | 1.5 x 1.5 | 2305 | 99 | 90 | 38 | Internal | No |
| ST150 Quad | 4 | Silicon | TO-8 | 1.5 x 1.5 | 2305 | 99 | 90 | 38 | Internal | No |
| ST60 Dual | 2 | Silicon | TO-5 | .61 x .61 | 621 | 98 | 160 | 18 | Internal | No |
| ST60 Quad | 4 | Silicon | TO-5 | .61 x .61 | 621 | 98 | 160 | 18 | Internal | No |
| T34 Compensated | 3 | Thin Film | TO-8 | .16 x .41 | 1570 | 99 | 16 | 38 | Internal | Standard |
| TM343 | 3 | Thin Film | TO-8 | .16 x .41 | 1008 | 88 | 38 | Internal | Standard |
